EasyWrap 165T
EasyWrap Trailing Bale Wrapper
Model Comparison
- 36 RPM
- 40 RPM
Product Features
1
2
3
4
Wrapping Table
Using four highly durable textile belts, the wrapping table rolls the bale effectively, and a special coating on the rollers prevents the belts from slipping. For optimal overlap, the belts form a deep cradle to hold the bale firmly in place.
| Name | EasyWrap 165T |
|---|---|
| Bale Width | 1,000 mm |
| Bale Diameter | 1,500 mm |
| Length (approx.) | 3,450 mm |
| Height (approx.) | 3,068 mm |
| Width (approx.) | 2,540 mm |
| Bale Weight Max. | 1,750 kg |
| Film Width | 750 mm |
| Film Stretch Min. | 55 % |
| Film Stretch Max. | 70 % |
| Tyre Size | 10.0 / 75-15.3 |
| Name | EasyWrap 165T |
|---|---|
| Hydraulic System | 1 SA and 1RL |
| Oil Flow Min. | 22 l/min |
| Oil Flow Max. | 45 l/min |
| Attachment | Trailing |
| Electric Connector | 3-pin Connector and InCab |
| Wrapping Speed Max. | 40 RPM |
| Name | EasyWrap 165T |
|---|---|
| Full Automatic Function | |
| Two Large Driven Rollers | |
| Two Large Driven Rollers | |
| Single Arm Wrapper | |
| Wrapping Arm with Integral Brake and Angle Sensor | |
| Hydraulic Roller Control | |
| Three Point Attachment | Cat III |
| Front End Bale Controlling Roll | |
| Single Axle without Brakes |
| Name | EasyWrap 165T |
|---|---|
| Bale Turner with Wheel | |
| Film Roll Holders (8 films) | |
| Optional Bobbins | |
| Bale Cloth | |
| ISOBUS Retro Fit Cable | |
| External Control | |
| Left-hand Wheel Weight | |
| Work Lights | |
| ISOBUS In Cab Monitor | CCI800 |
