RTV-X1140W

Kubota RTV-X Crew Utility Vehicle

Model Comparison Product Features Specifications
Kubota RTV-X Crew Utility Vehicle previewKubota RTV-X Crew Utility Vehicle
Kubota’s RTV-X Crew offers the ultimate in power and versatility, designed for heavy-duty applications in the toughest environments. Powered by Kubota’s 24.8HP engine and featuring Kubota’s unique Variable Hydrostatic Transmission, the RTV-X Crew delivers best in class control on rugged terrain. Experience exceptional versatility with the RTV-X Crew's unique design, allowing you to change easily from transporting materials to diving more passengers with a convenient second row of seating.

Model Comparison

Finance Offers
Download Brochure
  • 24.8 hp
  • 24.8 hp
  • 24.8 hp
  • 21.6 hp
  • 21.6 hp
  • 21.6 hp
  • 24.8 hp
  • 24.8 hp
  • 24.8 hp

Product Features

kubota previewkubota
1
2
3
4
5
6
7

Engine

The Kubota RTV-X Crew boasts a powerful 24.8HP liquid-cooled diesel engines for long and strenuous tasks. The 3 cylinder engines are quiet, powerful and are renowned bullet proof marvels at the true heart of the RTV-X Crew.

Engine

The Kubota RTV-X Crew boasts a powerful 24.8HP liquid-cooled diesel engines for long and strenuous tasks. The 3 cylinder engines are quiet, powerful and are renowned bullet proof marvels at the true heart of the RTV-X Crew.

Specifications

Download Brochure
Engine
Name RTV-X1140W
Engine Model Kubota D1105
Fuel Type Diesel
Cylinders 3
Engine Gross 24.8 hp
Displacement 1,123 cc
Fuel Tank Capacity 30 l
Rated Speed 3,000 rpm
Name RTV-X1140W
Transmission Variable Hydro Transmission
Drive Method Selectable 4WD
Brakes Wet Disc
Differential Front Limited-slip differential
Differential Rear Foot operated differential lock
Gear Selection Hi-Lo Range, forward, neutral, reverse,
Steering Hydrostatic Power Steering
Name RTV-X1140W
Front Suspension Independent, Dual A-arms with adjustable spring preload
Front Suspension Travel 205 mm
Rear Suspension Independent with coil over shock
Rear Suspension Travel 205 mm
Name RTV-X1140W
Tubular Overhead Structure 50.8 mm
Seat Belts 2-point
Certification SAE J2194 and OSHA 1928 ROPS and ANSI B71.9
Name RTV-X1140W
Front 25 x 10-12
Rear 25 x 10-12
Name RTV-X1140W
Maximum High Speed 40 km/h
Name RTV-X1140W
Length 3,610 mm
Width 1,605 mm
Height 2,025 mm
Tread Front 1,280 mm
Tread Rear 1,280 mm
Wheelbase 2,495 mm
Turning Radius 5.2 m
Ground Clearance Front 285 mm
Ground Clearance Rear 240 mm
Weight 1,075 kg
Towing Capacity 590 kg
Payload Capacity 739 kg
Name RTV-X1140W
Material Steel
Length 1,300 mm
Width 1,465 mm
Depth 285 mm
Bed Height 900 mm
Volume 0.54 m3
Cargo Bed Capacity 500 kg
Dumping System Hydraulic
